XF-T7 RoHS Analyzer ensures compliance with RoHS 1.0, EN71, and other environmental protection directives. Designed to detect hazardous heavy metals, including lead, mercury, cadmium, and halogens, it delivers fast, stable, and accurate results. AERB Type approved RoHS analyser to meet Domestic Statuatory compliance.
Key Highlights of T7 RoHS Analyzer
Smart FP Algorithm for Ultimate Accuracy
Detects hazardous metals like lead, mercury, and cadmium down to 2 ppm with ±2.5% accuracy, ensuring RoHS and EN71 compliance.
Built-in Industrial Computer for Seamless Operation
Equipped with Intel 11th Gen i3 processor and Windows 11 Pro, offering fast processing, stable performance, and secure RoHS testing automation.
Multi-Element Analysis in One Test
Simultaneously detects up to 30 elements, from Sulfur (16) to Uranium (92), making it ideal for industrial RoHS screening.
Reporting & Integration
Features custom TCP/IP API for extranet control, enabling real-time status monitoring, multi-point testing, and automated compliance reporting.
| Parameter | Details |
|---|---|
| Input Voltage | AC 100-240V, 50Hz |
| Machine Size | 500mm x 400mm x 368mm |
| Test Chamber Size | 373mm x 343mm x 120mm |
| Detection Range | S (No.16) to U (No.92) |
| Detection Limit | 2 ppm (optimal matrix effect) |
| Accuracy | Relative error < ±2.5% |
| Operating System | Windows 11 Pro, built-in industrial PC |
| X-ray Tube | 50KV/1mA Tungsten target |
| Noise Level | 50 dB |
| Weight | Net: 43KG / Gross: 58KG |
| Industry | Use Case |
|---|---|
| Electronics | RoHS compliance testing for circuit boards, components, and solders. |
| Toy Manufacturing | EN71 compliance verification for hazardous substances. |
| Automobile | Halogen-free and heavy metal testing in car parts. |
| Medical Devices | Ensuring RoHS compliance in medical equipment. |
| Jewelry & Metals | Checking for harmful elements in metal alloys. |
Aurum 5 Pro delivers SDD-level accuracy at a cost-effective price....
Aurum5 FSDD Pro is our Flag-ship EDXRF Spectrometer with wide...
Aurum5i FSDD Pro – The Pinnacle of XRF Gold Testing...
Yes, our product range suits businesses of all sizes. You can contact our sales team to discuss your requirements and receive guidance on products.
All Maxsell products come with a 12-month manufacturing warranty.
Understanding your requirements, we may offer exclusive configurations, but we’re unable to customize the product. Please note, this is subject to availability and ask.
Yes, our post-sales team will take care of the installation and offer you complete guidance on how to use the instruments.
